As2074 C4
Description
Basic Info.
| Model NO. | EB3569 |
| Surface Treatment | Natural |
| Range of Applications | Industrial |
| Type | Grate Grate |
| Fuel | All |
| Transport Package | Plywood Case |
| Trademark | EB |
| Origin | China |
| Production Capacity | 500000kilograms/Year |
Product Description
Product Description:
Mechanical Grate Incinerators can be divided into horizontal reciprocating grate system, inclining grate system from the
layout of grates. Or they can be divided into three types from the moving ways: Push type reciprocating grate system,
Inverse push type reciprocating grate system and Rolling type reciprocating grate system.
The grate system can be composed of moving grate bars and fixing grate bars. The structure and shape of the two grate
bars are designed to be same so that it is very convenient for replacement. The width of grate system will be decided by
handling capacity of waste. When calorific value is designed to be 6270kJ/kg, the surface temperature of grate bars is
400~500 centi-degree, the service life of grate bars can be about 5 years.
The key element for incinerators is grate bars. The chemical composition is as follows:
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5~10 days if the goods are in stock.Or it is 45 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment
irrevocable LC at sight.
| Material Grade | Chemical Composition(%) | |||||
| C | Si | Mn | P | S | Cr | |
| RTCr16 | 1.6-2.4 | 1.5-2.2 | <1.0 | <0.1 | <0.05 | 1.5-1.8 |
| RTCr28 | 0.5-1.0 | 0.5-1.3 | 0.5-0.8 | <0.1 | <0.08 | 26-30 |
| Material Grade | - | Chemical Composition(%) | |||||
| C | Si | Mn | P | S | Cr | ||
| Middle Si Cast Iron | RTSi-5.5 | 2.2-3.0 | 5.0-6.0 | <1.0 | <0.2 | <0.12 | 0.5-0.9 |
| Chromium Cast Iron | RTSi-5.5 | 2.8-3.6 | 1.5-2.5 | <1.0 | <0.3 | <0.12 | 0.5-1.1 |
| Chromium Cast Iron | RTSi-5.5 | 2.8-3.6 | 1.7-2.7 | <1.0 | <0.3 | <0.12 | 1.2-1.9 |
